SGS Test Reports for MAISHI HDPE Rockshield

MAISHI HDPE rockshield pipeline protection mesh has been tested by SGS for tensile strength, tear strength, compressive strength and low-temperature flexibility down to -40 °C. The reports below cover the latest SGS test series (September 2026) and an earlier third-party tensile and impact test.

Verify every report with the issuing laboratory. Each report below is issued to HEBEI MAISHI WIRE MESH MANUFACTURE CO., LTD. If a supplier shows you one of these reports under a different company name, the laboratory record will reveal it. Report numbers and QR codes are left visible for this purpose.

Tensile Strength Test (ISO 10319:2024)

Report No.SZIN2609002661PL01_EN
LaboratorySGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch
Issue date2026-09-20
Standard / methodISO 10319:2024 wide-width tensile test
Key resultTransverse: 2.94 kN/m at 144.0 % strain. Lengthways: 8.17 kN/m at 54.6 % strain (5 specimens).
How to verifyScan the QR code on the cover page, or enter the report number at check.sgsonline.com.cn. You can also e-mail CN.Doccheck@sgs.com.
Full reportRequest the complete report No. SZIN2609002661PL01_EN
MAISHI Tensile Strength Test (ISO 10319:2024) report No. SZIN2609002661PL01_EN - cover page
Cover page (watermarked preview)
MAISHI Tensile Strength Test (ISO 10319:2024) report No. SZIN2609002661PL01_EN - results page
Results page (watermarked preview)

Tear Strength Test (ASTM D624)

Report No.SZIN2609002661PL04_EN
LaboratorySGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch
Issue date2026-09-16
Standard / methodASTM D624-00(2020), Type C specimen
Key resultMD: 5.3 kN/m. TD: 13.6 kN/m (specimen thickness 5.109 mm).
How to verifyScan the QR code on the cover page, or enter the report number at check.sgsonline.com.cn. You can also e-mail CN.Doccheck@sgs.com.
Full reportRequest the complete report No. SZIN2609002661PL04_EN
MAISHI Tear Strength Test (ASTM D624) report No. SZIN2609002661PL04_EN - cover page
Cover page (watermarked preview)
MAISHI Tear Strength Test (ASTM D624) report No. SZIN2609002661PL04_EN - results page
Results page (watermarked preview)

Compressive Strength Test (ASTM D1621)

Report No.SZIN2609002661PL06_EN
LaboratorySGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch
Issue date2026-09-23
Standard / methodASTM D1621-16 (Reapproved 2023)
Key resultCompressive stress at 10 % strain: 0.441 MPa (thickness direction).
How to verifyScan the QR code on the cover page, or enter the report number at check.sgsonline.com.cn. You can also e-mail CN.Doccheck@sgs.com.
Full reportRequest the complete report No. SZIN2609002661PL06_EN
MAISHI Compressive Strength Test (ASTM D1621) report No. SZIN2609002661PL06_EN - cover page
Cover page (watermarked preview)
MAISHI Compressive Strength Test (ASTM D1621) report No. SZIN2609002661PL06_EN - results page
Results page (watermarked preview)

Low-Temperature Bend Test at -40 °C (ASTM D2136)

Report No.SZIN2609002661PL07_EN
LaboratorySGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch
Issue date2026-09-23
Standard / methodASTM D2136-19ε1, 4 h conditioning, 3 mm mandrel
Key result-40 °C for 4 h: 3 of 3 specimens passed, no cracking under 5x magnification.
How to verifyScan the QR code on the cover page, or enter the report number at check.sgsonline.com.cn. You can also e-mail CN.Doccheck@sgs.com.
Full reportRequest the complete report No. SZIN2609002661PL07_EN
MAISHI Low-Temperature Bend Test at -40 °C (ASTM D2136) report No. SZIN2609002661PL07_EN - cover page
Cover page (watermarked preview)
MAISHI Low-Temperature Bend Test at -40 °C (ASTM D2136) report No. SZIN2609002661PL07_EN - results page
Results page (watermarked preview)

Tensile, Elongation and Impact Test (HBMS-800)

Report No.DB-20130605-004
LaboratoryQingdao Dongbiao Testing Service Co., Ltd.
Issue date2013-07-10
Standard / methodISO 10319-2008; GB/T 1732-1993 (impact)
Key resultWarp: 10.9 kN/m, 65 % elongation. Weft: 8.9 kN/m, 73 % elongation. Impact resistance: 47 kg·cm.
How to verifyContact the issuing laboratory and quote the report number.
Full reportRequest the complete report No. DB-20130605-004
MAISHI Tensile, Elongation and Impact Test (HBMS-800) report No. DB-20130605-004 - cover page
Cover page (watermarked preview)
MAISHI Tensile, Elongation and Impact Test (HBMS-800) report No. DB-20130605-004 - results page
Results page (watermarked preview)

Only the cover page and one results page of each report are shown online. The complete original report is sent on request after an inquiry, as a view-only link or as a PDF issued to your company name.
